- Product contains Latex
- No
- Sterility
- non-sterile
- Horizontal resolution (Lines)
- 1920
- Modes
- 5 presettings
- Scan mode
- progressive
- Video signal output
- HD-SDI 1080i, 720p (60 Hz), DVI-D 1080p (60 Hz), 3G-SDI 1080p
- Colour bars
- Yes
- to be used with (code)
- PV482, PV481, PV485
- Product Search Type
- Camerai Control Unit
- Discipline
- Cardiac / Thoracic Surgery, Urology, Arthroscopy
- Indication
- Laparoscopy, Hysteroscopy
- On-screen display
- Yes
- Aesculap Product Groups
- Endoscopic Technology
- Safety class acc to EN 60601-1
- I
- Tested acc to norm
- EN 60601-1, EN 60601-1-2
- Protection level acc EN_606011
- CF
- Disposable / Reusable
- reusable
- Power supply
- 100-240 V AC, 50/60Hz
- Product family
- Equipment
- Button functions
- individually adjustable
- Weight CCU
- 7 KG
- Maximum power consumption
- 60 VA
